LED Shop Light

Item No.: NG-SL
ETL cETL approved
120V Input Voltage
Built-in AC Linear Scheme Drive Power Supply
Die Casting Aluminum Heat Sink
6K High voltage surge test approved SMD2835
130lm w Led Chips / 50 000hrs Lifespan
No Magnetic Disturbance Driver Design
Quantity
-
+
Description Overseas Warehouse FAQ
Description

Series

Lumens Size(mm) Beam Angle(Degree) Electrical Data LED Type Color Temperature Color Rendering Index

NG-SL-80W


10400Lm


 1200 120 degree Input Voltage
120V士10%
  50~60Hz
Power Factor(%)
>90
SMD 2835 Chips WW3000K
NW4000K
DW5000K
CW5700K
70 70 CRI
80 80 CRI
90 80 CRI

NG-SL-100W


 13000Lm  1200

NG-S-120W

 15600Lm  1200

led shop lightled shop light dimensions
  led post top light led parking lot light led bulb light led temporary work
  LED Post Top Lights LED Parking Lot Light LED High Bay Light
LED Corn Bulb Light

LED Temporary Work LED Shop Light

 Voltage

AC100-277V AC100-480V AC100-480V AC100-480V AC100-277V AC120V士10%
  Applications Outdoor use, garden,parking lot, street, area, roadway, driveway, square, tennis court and so on Outdoor use, parking lot, street, area, roadway, driveway, square, tennis court and so on IndoorUse,shop,warehouse,
workshop,garage,office, and so on
Indoor and Outdoor Use,
warehouse, parking lot, street, area, roadway, driveway, square, tennis court and so on
Indoor and Outdoor Use, Job site, construction site, tunnel, garage, workshop and so on IndoorUse,shop,warehouse,
workshop,garage,office, and so on

 Lumens

7800LM~19500LM 14000LM~44800LM 14000LM~48000LM 4332LM~39280LM 8400LM~21000LM 5200LM~10400LM

Feature

Dusk to Dawn Dusk to Dawn Super Bright Super Bright Super Bright Super Bright
Overseas Warehouse
led shop light

US&Canada Warehouse Fast& Convenient Delivery Located in KY,OH,TX.Where we ship the lights depends on what products you need and our inventory conditions. After got inquiry we will check which warehouse ship the light to you.

led shop light
FAQ

Q: Does this lamp have any certification?

A: Yes, this led shop light is ETL cETL certified. And we provide 5 years warranty. Anything wrong during the warranty period, well solve it for you.

Q: How many lights can I linked in one time?

A: This led shop light is linkable max to 500watt, that means you can link 6 lights for 80watt together, 5 lights for 100watt and 4 lights for 120watt.

Q: Can it be plugged into 220V? or 277V?

A:  Our factory stock led shop light can be only used at 120V±10%, but if you need working in 220V, 240V or 277V which need customize and only can be used in single voltage.



Q: What length of this lights?

A: The regular length is 1.2m/4ft, we also provide 0.6m/0.9m/1.5m for choice, if your order quantity is big enough, we can do it as your request.

Q: Is this light ceiling mounted?

A: Yes, but not only ceiling mounted, it can be also hanging mounted. All accessories needed for installation, well prepared them for you, including 1x 35inch on/off pull chain, 1x mini screwdriver, 1x short T5 connector, 1x 20inch T5 linking cord, 1x 70in US plug cable, 2x 47inch suspended chains, 2x mounting clips, 4x plastic anchors, 2x brackets, 4x M4 screws, 2x hook screw sets.

Q: I will plug these into a switch controlled outlet. Can I bypass the pull chain switch so that the light will always come on with the wall switch?

A: Sure, you can. This led shop light have plug, no need to worry about it.

Q: If these are all linked together, can a single power cord turn them all on at the same time?

A: Yes, if these linkable led shop lights are all linked together, and you do not want to turn on/off the led shop light through the on/off pull chain on the shop light one by one, you could install a switch to turn them all on at the same time.

Q: These come with mounting clips. Would two clips be sufficiently strong to hang this fixture vertically from ceiling trusses?

A: Sure, The mounting clips are sufficiently strong to hang this led shop light vertically from ceiling trusses, our engineer team test the mounting clips to hang and we also installed the linkable led shop light hanging mounting in our office and factory. Dont worry about it.
