LED Shop Light

Item No.: NG-ST10
ETL cETL approved
120V Input Voltage
Built-in AC Linear Scheme Drive Power Supply
Die Casting Aluminum Heat Sink
6K High voltage surge test approved SMD2835
130lm w Led Chips / 50 000hrs Lifespan
No Magnetic Disturbance Driver Design
Quantity
-
+
Description Overseas Warehouse FAQ
Description

Series

Lumens Size(mm) Beam Angle(Degree) Electrical Data LED Type Color Temperature Color Rendering Index

NG-ST10-40W


5200Lm


 1100 120 degree Input Voltage
120V/60Hz
Power Factor(%)
>90
SMD 2835 Chips 3000K
4000K
5000K
5700K
Ra>=80

NG-ST10-60W


 7800Lm  1100

NG-ST10-80W

 10400Lm  1100

led shop light led shop light dimensionsled shop light structureled shop lightled shop light
  led post top light led parking lot light led bulb light led temporary work led garage light
  LED Post Top Lights LED Parking Lot Light LED High Bay Light
LED Corn Bulb Light

LED Temporary Work LED Garage Light

 Voltage

AC100-277V AC100-480V AC100-480V AC100-480V AC100-277V AC100-277V
  Applications Outdoor use, garden,parking lot, street, area, roadway, driveway, square, tennis court and so on Outdoor use, parking lot, street, area, roadway, driveway, square, tennis court and so on IndoorUse,shop,warehouse,
workshop,garage,office, and so on
Indoor and Outdoor Use,
warehouse, parking lot, street, area, roadway, driveway, square, tennis court and so on
Indoor and Outdoor Use, Job site, construction site, tunnel, garage, workshop and so on IndoorUse,shop,warehouse,
workshop,garage,office, and so on

 Lumens

7800LM~19500LM 14000LM~44800LM 14000LM~48000LM 4332LM~39280LM 8400LM~21000LM 8400LM~21000LM

Feature

Dusk to Dawn Dusk to Dawn Super Bright Super Bright Super Bright Super Bright
Overseas Warehouse
led shop light

US&Canada Warehouse Fast& Convenient Delivery Located in KY,OH,TX.Where we ship the lights depends on what products you need and our inventory conditions. After got inquiry we will check which warehouse ship the light to you.

led shop light
led shop light led shop light
US DOMESTIC DELIVERY                                 CANADA DOMESTIC DELIVERY
KY WAREHOUSE:                                 CANADA WAREHOUSE:
2125 Gate Blvd, H+ebron, KY 41048                                 Gormley,Ontario,CA
OH WAREHOUSE:
10 Mill Road - Bellville, OH 44813
TX WAREHOUSE:
300 W Airtex Blvd, Suite 200, Houston, TX 77090
FAQ

Q: Does this lamp have any certification?

A: Yes, this led shop light is UL CUL certified. And we provide 5 years warranty. Anything wrong during the warranty period, we’ll solve it for you.

Q: How many lights can I linked in one time?

A: This led shop light is linkable max to 500watt, that means you can link 6 lights for 80watt together, 5 lights for 100watt and 4 lights for 120watt.

Q: Can it be plugged into 220V? or 277V?

A: Our factory stock led shop light can be only used at 120V±10%, but if you need working in 220V, 240V or 277V which need customize and only can be used in single voltage.


Q: What length of this lights?

A: The regular length is 1.2m/4ft, we also provide 0.6m/0.9m/1.5m for choice, if your order quantity is big enough, we can do it as your request.

Q: Is this light ceiling mounted?

A: Yes, but not only ceiling mounted, it can be also hanging mounted. All accessories needed for installation, we’ll prepared them for you, master box is 4pcs. With on/off pull chain & 3 prong power cord.including 8x Buckles, 8x hook screw sets, 16x 4ft suspended chains, 8x mounting clips, 16x plastic anchors, 16x M4 screws.


Q: I will plug these into a switch controlled outlet. Can I bypass the pull chain switch so that the light will always come on with the wall switch?

A: Sure, you can. This led shop light have plug, no need to worry about it.

Q: If these are all linked together, can a single power cord turn them all on at the same time?

A: Yes, if these linkable led shop lights are all linked together, and you do not want to turn on/off the led shop light through the on/off pull chain on the shop light one by one, you could install a switch to turn them all on at the same time.

Q: These come with mounting clips. Would two clips be sufficiently strong to hang this fixture vertically from ceiling trusses?

A: Sure, The mounting clips are sufficiently strong to hang this led shop light vertically from ceiling trusses, our engineer team test the mounting clips to hang and we also installed the linkable led shop light hanging mounting in our office and factory. Don’t worry about it.

Q: Can you remove the beside 2 aluminum reflector wings if we don’t need it?

A:Yes, sure, we can remove it make cost and shipping is lower as long as you can meet MOQ request.
