| SIZE | SYSTEM WATTS |
VOLTAGE | NEMA | EPA | CRI | LUMENS (4000K) |
LPW (4000K) |
LUMENS (5000K) |
LPW (5000K) |
LUMENS (5700K) |
LPW (5700K) |
| Small Size | 350W | 120-277V/347-480V | 4Hx4V | 1.8911 | 70 | 51000lm | 146 Im/W | 51000lm | 146lm/W | 49500lm | 141 Im/W |
| Small Size | 505W | 120-277V/347-480V | 4Hx4V | 1.8911 | 70 | 70000lm | 139 Im/W | 70000lm | 139 Im/W | 68000lm | 135Im/W |
| Small Size | 600W | 120-277V/347-480V | 4Hx4V | 1.8911 | 70 | 82000lm | 137 Im/W | 82000lm | 137 Im/W | 80000lm | 133Im/W |
| Large Size | 500W | 120-277V/347-480V | 4Hx4V | 2.5471 | 70 | 71000lm | 142 Im/W | 71000lm | 142Im/W | 69000lm | 138Im/W |
| 3Hx3V | 2.5471 | 70 | 68160lm | 136 Im/W | 68160lm | 136lm/W | 66240lm | 132Im/W | |||
| Large Size | 600W | 120-277V/347-480V | 4Hx4V | 2.5471 | 70 | 84000lm | 140 Im/W | 84000lm | 140 Im/W | 82000lm | 137 Im/W |
| 3Hx3V | 2.5471 | 70 | 80640lm | 134 Im/W | 80640lm | 134Im/W | 78720lm | 131 Im/W | |||
| Large Size | 650W | 277-480V | 4Hx4V | 2.5471 | 70 | 91000lm | 140 Im/W | 91000lm | 140Im/W | 88000lm | 135Im/W |
| 3Hx3V | 2.5471 | 70 | 87360lm | 134 Im/W | 87360lm | 134Im/W | 84480lm | 130 Im/W | |||
| Large Size | 850W | 120-277V/347-480V | 4Hx4V | 2.5471 | 70 | 118000lm | 139 Im/W | 118000lm | 139Im/W | 112000lm | 132 Im/W |
| 3Hx3V | 2.5471 | 70 | 113280lm | 133 Im/W | 113280lm | 133Im/W | 107520lm | 126lm/W |
